Description:
EQUIPPED WITH:
01. TANK – 1 PC.
TYPE: VERTICAL, CYLINDRICAL, WITH RUBBER MEMBRANE INSIDE CAPACITY: 50 LITRES
MATERIAL: STAINLESS STEEL 316L
WORKING PRESSURE: 6 BAR
MARINE STANDARD
DNV CERTIFICATION: NOT REQUIRED
02.SKID MADE OF STAINLESS STEEL 1 PC.
03. ELECTRICAL BOX (CONTROL UNIT) – 1 PC.
MATERIAL: GALVANIZED BLACK STEEL, POWDER PAINTED 9003 FULLY EQUIPPED, MADE ACCORDING TO CLASS SOCIETY RULES POWER SUPPLY: 3x400V 50Hz
PROTECTION: IP54
INCLUDES 2 PCS OF VFD FOR 2 PUMPS (ONE TO ONE)
04. PUMP (SELF PRIMING) | 8 m3/h / 6 BAR – 2 PCS. PUMP CLASS CERTIFICATE: 3.1
SUITABLE FOR FRESH WATER
05. WIKA PRESSURE GAUGE MADE OF STAINLESS STEEL – 4 PCS.
06. PRESSURE GAUGE VALVE – 4 PCS.
07. SAFETY VALVE – 1 PC.
08. BALL VALVE – 4 PCS.
09. NON-RETURN VALVE – 2 PCS.
10. PRESSURE TRANSMITTER – 1 PC.
11. NAME PLATE MADE OF STAINLESS STEEL – 1 PC.
12. WATER INPUT/OUTPUT CONNECTIONS WITH FLANGES – 1 SET
13. PUMP 3.1 CERTIFICATES: INCLUDED
14. EXPANSION TANK 50L AS LOOSE SUPPLY TO BE CONNECTED DURING INSTALATION PROCESS BY SHIPYARD
